The Diffusion Cloud Chamber is used to view high energy alpha particles, lower energy beta particles, and electrons produced by gamma rays interacting with gas molecules. The Chamber allows for the viewing of cosmic rays without the need for dry ice or external illumination.
- 1 x
Cloud Chamber
- 1 x
12 VDC Power Adapter (6 A)
- 1 x
Water Circulation Pump
- 1 x
Two Rubber Hoses
- 1 x
Extraction Pipette
- 1 x
Source Holder and Stopper
- 1 x
High Voltage Connection Cable
- 1 x
SpecTechu2122 Coupon for Pb-210 Source Needle
- Powered by 12V DC power adapter
- Built-in LED lamps for illuminating the particle trails
- Uses ice water instead of dry ice
- Water circulation pump
- Built-in high voltage (~800V) power supply for clearing the chamber of unwanted ions
- Diameter : 15 cm 12 VDC Power Adapter (6 A)
- Water Circulation Pump : 120 V/ 60 Hz, 3 W, 180 liter/hr
- Built-in High Voltage Source : ~800 VDC with 108 Ω protection resistor
- Rubber Hoses : 0.25" ID (6.4 mm ID), 60 cm long
- High Voltage Connection Cable : 22 cm long, Banana plug to ring lug Eight Amber LEDs
